VS320D-RS12

2U Intel^® dual-controller SAN 3.0 storage server designed for SMB workloads. It supports up to 12-bay 3.5" slots, scale-up capability up to 10.8PB with cache-to-flash technology. 12 LANs per controller and eight onboard 10GbE SFP for iSCSI.

Datasheet

Add to compare

Features

Specifications

Resources

Products

Key Features

A dual active-active controller configuration powered by quad-core Intel Xeon^® processor. Scalable up to 492 drive bays, up to 20 ASUS expansion units or four third-party JBODs, supporting SAS, NL-SAS and SED drives connected via SAS 3.0 12Gb/s interface.
Excellent performance with 12.8GB/s and 1.3M IOPS, outstanding scale-up capability up to 10.8PB.
Each controller with built-in four-port 10 GbE (SFP+) and maximum 12 LANs, allows direct connection to multiple LANs without switches.
It supports DDR4 ECC DIMM, which can be upgraded to 512GB, with cache-to-flash solution to protect cache data in power outage.
ASUS Storage Manager is a flash-based storage-management system, enabling intuitive data access within a five-minute installation. It provides the flexibility and intelligence for hybrid storage systems.
Scalable LAN expansion includes two- or four-port 16Gb FC/ 25Gb SFP28 and two-port 32Gb FC and four-port 10GbE iSCSI SFP+.
Designed for enterprise IT, media editing, large surveillance, small to medium businesses and HPC.
