• AMD-based rack server for HPC and AI workloads

    ASUS RS720A-E13-RS8U is an efficient, versatile server powered by dual AMD EPYC™ 9005-series processors, delivering exceptional performance for demanding enterprise workloads. Built on the advanced 3nm Zen5/5c architecture, these processors offer up to 192 cores, 384 threads and clock speeds of up to 5GHz, making them ideal for AI/ML processing, data analytics and virtualization. RS720A-E13-RS8U is optimized for seamless integration in modern data centers, offering high efficiency and compatibility across diverse IT environments.

    ASUS RS720A-E13-RS8U with dual AMD EPYC™ 9005-series processors

  • Flexible and expandable server for multi-tasking

    With the advanced x86 architecture and high CPU density, RS720A-E13-RS8U enhances computing efficiency and integrates seamlessly into existing data center infrastructures. This versatile server is designed for scalability, offering up to 3TB of memory and supporting various types of cards, including networking, RAID for flexible storage configurations. Its 80® PLUS Titanium redundant power supplies ensure optimal energy efficiency, reducing operational costs.

    System Layout Panel Layout Block Diagram
    • This is a line graph that helps people understand the locations of the key components on this server. This is a line graph that helps people understand the locations of the key components on this server.
      1 1 2 3 4 5 6 7

      110 x Expansion Slots (8 PCIe + 2 OCP3.0)

      22 x DIMM.2 (Up to 22110)

      38 x 2.5” Tool-less Hot-swap drive bays

      41+1 3200W/2700W 80 PLUS Titanium PSU

      5Dual AMD Turin CPU (TDP: 500W)

      624 x DDR5 DIMMs (1DPC)

      76 x 6056 Tool-less hot-swappable Fan Module

    • Front Panel Rear Panel
      • This is a line graph that helps people understand the locations of the key components on this server. This is a line graph that helps people understand the locations of the key components on this server.
        1 2 3

        1[Bay 1 ~ 8] NVMe/SATA/SAS*

        22 x USB3.2 Gen1

        3PWR/Location Button & LED

        8NVMe/SATA/SAS*

        *SAS support only from optional SAS HBA/RAID card

      • This is a line graph that helps people understand the locations of the key components on this server. This is a line graph that helps people understand the locations of the key components on this server.
        1 2 3 4 5 6 7 8 9 10 11 12 13

        12 x PCIe Gen5 x8 (FHFL) or 1 x PCIe Gen5 x16 (FHFL)

        22 x PCIe Gen5 x8 (FHFL) or 1 x PCIe Gen5 x16 (FHFL)

        32 x PCIe Gen5 x8 (FHFL) or 1 x PCIe Gen5 x16 (FHFL)

        4Power switch/LED

        5DM LAN port*

        62 x USB 5Gbps portsv

        7PCIe Gen5 x16 (FHHL)

        8Mini Display Port

        9Location switch/LED

        10Debug Port

        11OCP3.0 Gen5 x16

        12PCIe Gen5 x16 (FHHL)

        13OCP3.0 Gen5 x16

        *The DM LAN port is for ASUS ASMB12-iKVM controller only.

    • This is a block diagram, illustrating the server’s key components and functionality for easy understanding

      *All storage can support SAS through HBA/RAID card.

  • Scalable modular architecture for seamless integration

    RS720A-E13-RS8U features a modular DC-MHS architecture that ensures seamless integration and high performance in data center environments. Its scalable design allows businesses to adapt to changing IT workloads by adding or removing modules without disruption. This flexibility improves operational efficiency, simplifies system management and supports phased upgrades. The architecture optimizes capital expenditure and resource use, reducing upfront costs. Additionally, modular components can be replaced or upgraded quickly, minimizing downtime and ensuring continuous operations. The DC-MHS architecture also incorporates advanced cooling and power management systems, improving energy efficiency, reducing operational costs, and supporting sustainability efforts.

    • M-FLW (Modular Hardware System Full Width)

      M-FLW (Modular Hardware System Full Width):

      Optimizes server utilization for high-performance computing tasks like AI training and big data analytics.

    • DC-SCM (Data Center Secure Control Module)

      M-PIC (Modular Hardware System Platform Infrastructure Connectivity):

      Enables seamless communication and data transfer between different parts of the server, improving overall performance.

    • M-PIC (Module of Platform Infrastructure Connectivity)

      DC-SCM (Data Center Secure Control Module):

      Enhances system security by providing a trusted foundation for server operations and remote management.

  • Air-cooled solutions for excellent performance

    RS720A-E13-RS8U features an optimized air-cooled thermal solution with a 2U chassis and independent airflow channels, supporting up to 500W. Its advanced air-duct system improves airflow and reduces fan usage, enhancing cooling efficiency under heavy loads. The modular design also allows easy configuration offering high performance and flexibility for varying workloads.

    Pause
    press the play button to play ESC N8-E11/ESC N8-E11V product video

  • Toolless design for fast, simple maintenance

    ASUS has redesigned the server-chassis structure for optimal airflow, without compromising on specifications, enhancing cooling efficiency. With a quick-release top cover and a streamlined airflow system, you can manage cables and components effortlessly, reducing maintenance time. This creates a seamless airflow path from front to back, efficiently dissipating heat and keeping the system running cool and stable, streamlining upkeep and minimizing downtime.

    • Top cover of the server

      Effortless top-cover design

    • Remove the fab bar with hands

      Fan bar design

    • remove the DIMM.2 with hands

      Tool-less DIMM.2 installtion

    • The removeable DC-SCM card

      DC-SCM card

    • Two hands to hold the Air Duct

      Air Duct

  • World Records Leadership

    ASUS holds the most amount of records in dual-socket (2P) and single-socket (1P) on SPEC CPU 2017 benchmark and dominate the computing performance. These top performance results provide a useful insight into compute-intensive workloads on different computer systems, enabling our customers to reduce complexity, tackle challenging workloads and accelerate system validations.

    Computing Performance Power Efficiency

    • ASUS servers feature Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for timesensitive applications such as financial services or data center operations.

      • The chip pattern shows a curve that rises and then levels off, indicating the CPU's frequency.
        Core Optimizer

        Maximizes the processor frequency in multi-core operations, avoiding frequency shifting for reduced latency.

      • The chip pattern shows a curve that rises up, indicating the CPU’s power acceleration
        Engine Boost

        Automatic power acceleration with an innovative voltage design to increase server overall performance.

      • Three horizontal lines have small squares placed on the line respectively
        Workload Presets

        Preconfigured BIOS server profiles based on workloads and benchmarks for improved performance and efficiency.

      * SPEC is a corporation formed to establish and endorse standardized benchmarks and tools to evaluate performance and energy efficiency of computer systems.

    • ASUS select servers achieved most power efficiency positions on the SPEC Power benchmark for energy efficiency and demonstrate to customers how they can achieve faster deployments and higher energy efficiency for their IT infrastructure.

      • On the left is a lightning symbol, with a semicircular arc added to the right side
        ASUS Power Balancer

        Adjust overall loading automatically based on real-time monitoring to decrease overall power consumption for Improved efficiency and cost/performance optimization.

      • The fan icon is at the top, with a horizontal bar-like curve below
        Thermal Radar 2.0

        Features intelligent fan-curve adjustments to fit the real-time server usage patterns and lower fan power consumption.

  • Server-management Solution

    BMC IT Infrastructure Management Software
    • Remote server management

      ASUS ASMB12-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.

      Learn more 〉
      A bar Chart for BMC Boot Time Comparison Across Chipsets
    • Streamline IT operations via a single dashboard

      ASUS Control Center (ACC) is remote IT management software designed for monitoring your hardware and software IT assets and inventory status and enabling seamless remote BIOS configurations and updates, efficient IT diagnostics and troubleshooting and enhanced security with Hotfix updates, allowing easier server management for any IT infrastructure.

      Learn more 〉
      A tablet, a monitor, and a smartphone, all displaying the ASUS Control Center interface.

  • Enhanced Security

    Hardware Root-of-Trust Solution Trusted Platform Module 2.0
    • Hardware Root-of-Trust Solution:Detect, recover, boot and protect

      ASUS servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.

      * Platform Firmware Resilience (PFR) module must be specified at time of purchase and is factory-fitted. It is not for sale separately.

    • Trusted Platform Module 2.0

      ASUS servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.
